Ultra-Flex

Ultra-Flex

Designed for high flexibility and durability, this hose features a sturdy, kink-resistant spiral wrap outer jacket, making it ideal for demanding applications such as cryogenic liquid cylinder (dewar) refilling and liquid withdrawal from dewar to equipment

Available size: DN8 (3/8″) to DN12 (1/2″)
Connection type: C-series bayonet, 37o JIC 1/2″-20 UNF (CGA-295), NPT Threaded
Integration Option: Tee, Elbow, Valve, Vacuum probe DV-6R
Vacuum Warranty: 1 year

Enquiry Product

Specific Enquiry

[ez-toc]

Tees, elbows, bayonets and valves can be incorporated with Ultra-Flex transfer hose for a customized LN2 piping system application
Both flexible and rigid sections can be combined as one spool
Select hoses are stocked for immediate delivery
Super insulation and proprietary chemical getters ensures long lasting vacuum integrity
Each hose is evacuated (10 -6 torr), helium leak checked (1 x10 -9 std cc/sec) and liquid nitrogen cold shocked before shipping
Vacuum insulation eliminates frost, ice and related safety hazards
